Fuel Cells

Fuel Cells: The Complete Guide — Types, Working Principles, Applications & Comparisons

In the quest for a sustainable and decarbonized world, fuel cells have emerged as one of the most promising clean energy solutions. Unlike traditional combustion engines or fossil-fuel power plants, fuel cells generate electricity through an electrochemical reaction — producing only water and heat as by-products. This means zero local emissions and higher efficiency.

But did you know there are multiple types of fuel cells? Each type has unique working principles, temperature ranges, fuel requirements, and real-world applications — from powering laptops to buses, buildings, and even large-scale power plants.

In this comprehensive guide, we’ll explain how fuel cells work, break down the different types, show where they’re used, and compare them so you can see which is best for what purpose.


How Does a Fuel Cell Work?

At its core, a fuel cell converts chemical energy directly into electrical energy through an electrochemical reaction — similar to a battery, but it doesn’t run down or need recharging as long as fuel is supplied.

Basic working principle:

  • Fuel (like hydrogen, methanol, or natural gas) is supplied to the anode side.
  • Oxygen (from air) is supplied to the cathode side.
  • At the anode, the fuel splits into electrons and protons.
  • The electrolyte allows only the protons to pass through; the electrons flow through an external circuit, generating electricity.
  • At the cathode, the protons, electrons, and oxygen combine to form water and release heat.

Each fuel cell type uses different fuels, electrolytes, and operating temperatures, which impact performance, cost, and application.


Types of Fuel Cells Explained in Detail

1. Proton Exchange Membrane Fuel Cell (PEMFC)

How it Works:
Uses a solid polymer membrane as the electrolyte. Hydrogen fuel splits at the anode into protons and electrons; the membrane allows only protons through while electrons generate electricity via an external circuit. Operates at relatively low temperatures (~60–80°C).

Typical Uses:

  • Automobiles: hydrogen fuel cell cars (like Toyota Mirai, Hyundai NEXO)
  • Buses & trucks
  • Backup power for data centers and telecom towers
  • Portable power packs

Advantages:

  • Fast start-up and shut-down
  • Lightweight and compact
  • Ideal for transportation

Challenges:

  • Requires pure hydrogen (sensitive to impurities)
  • Expensive platinum catalyst needed

2. Solid Oxide Fuel Cell (SOFC)

How it Works:
Uses a solid ceramic electrolyte that conducts oxygen ions. Operates at very high temperatures (600–1,000°C). Oxygen ions travel through the electrolyte to react with fuel (hydrogen or hydrocarbons) at the anode.

Typical Uses:

  • Large-scale stationary power generation
  • Industrial combined heat and power (CHP)
  • Distributed generation for commercial buildings
  • Auxiliary power units for heavy-duty vehicles

Advantages:

  • High electrical efficiency (up to 60%)
  • Can use various fuels: hydrogen, natural gas, biogas, syngas
  • Waste heat can be used for CHP, increasing total system efficiency to ~80–90%

Challenges:

  • High operating temperature means long start-up times
  • Expensive ceramic materials and sealing technologies needed

3. Phosphoric Acid Fuel Cell (PAFC)

How it Works:
Uses liquid phosphoric acid as the electrolyte. Operates at moderate temperatures (~150–220°C). Oxygen is supplied to the cathode, while hydrogen-rich fuel reacts at the anode.

Typical Uses:

  • Commercial & industrial CHP
  • Hospitals, hotels, and office buildings
  • Distributed power generation where heat recovery is needed

Advantages:

  • Proven technology with commercial installations worldwide
  • Good tolerance for fuel impurities
  • Efficient cogeneration of heat and power (overall efficiency ~70–80%)

Challenges:

  • Lower electrical efficiency (~40–50%) than SOFC or PEMFC
  • Bulky and heavy compared to newer fuel cell technologies

4. Molten Carbonate Fuel Cell (MCFC)

How it Works:
Uses a molten carbonate salt mixture as the electrolyte, operating at around 600–700°C. Carbon dioxide and oxygen are fed to the cathode where carbonate ions are formed, migrating through the electrolyte to react with hydrogen at the anode.

Typical Uses:

  • Utility-scale power generation
  • Large industrial facilities
  • Industrial CHP systems

Advantages:

  • Can use carbon-based fuels like natural gas or biogas directly
  • High electrical efficiency (~45–55%)
  • Waste heat usable for industrial processes

Challenges:

  • High temperature requires durable materials and corrosion control
  • Complex CO₂ management and system design

5. Alkaline Fuel Cell (AFC)

How it Works:
Uses an alkaline electrolyte (potassium hydroxide solution) and operates at low to medium temperatures (~60–90°C). Very efficient at splitting hydrogen and oxygen.

Typical Uses:

  • Space missions (NASA’s Apollo and Space Shuttle used AFCs)
  • Military applications
  • Some portable or backup power solutions

Advantages:

  • High efficiency (up to 70% in some cases)
  • Well-suited to pure hydrogen and oxygen environments

Challenges:

  • Sensitive to CO₂ contamination — needs purified hydrogen and air
  • Limited commercial use outside niche applications

6. Direct Methanol Fuel Cell (DMFC)

How it Works:
Uses a polymer electrolyte but runs directly on liquid methanol, eliminating the need for a fuel reformer. Methanol is oxidized at the anode to produce protons, electrons, and CO₂.

Typical Uses:

  • Small portable electronics (laptops, military field equipment)
  • Backup power for telecoms
  • Remote monitoring stations

Advantages:

  • Easy fuel storage and handling (liquid methanol)
  • Simpler system design compared to hydrogen-based fuel cells

Challenges:

  • Lower efficiency than hydrogen fuel cells
  • Methanol is toxic and flammable — needs careful handling

7. Reversible Fuel Cell (RFC)

How it Works:
Also known as regenerative fuel cells, these operate as both electrolyzers and fuel cells. In electrolyzer mode, they use surplus renewable electricity to split water into hydrogen and oxygen for storage. When electricity is needed, they operate as a fuel cell to convert stored hydrogen back into power.

Typical Uses:

  • Renewable energy storage in microgrids
  • Off-grid or remote systems with variable energy supply
  • Long-duration storage solutions for excess solar/wind energy

Advantages:

  • Combines hydrogen production and power generation in one unit
  • Ideal for integrating intermittent renewables

Challenges:

  • Still emerging — efficiencies, cost, and durability need improvement
  • Complex system management to switch between modes

Comparison of Fuel Cell Types

Fuel Cell TypeOperating TempElectrolyteTypical FuelBest ForElectrical Efficiency
PEMFC60–80°CPolymer membranePure hydrogenCars, buses, backup power40–60%
SOFC600–1,000°CSolid ceramicHydrogen, natural gasLarge CHP, industrial50–60%
PAFC150–220°CPhosphoric acidHydrogen-richBuildings, CHP40–50%
MCFC600–700°CMolten carbonate saltNatural gas, biogasUtility power, CHP45–55%
AFC60–90°CAlkaline solutionPure hydrogenSpace, niche portable50–70%
DMFC20–90°CPolymer membraneLiquid methanolPortable power20–30%
RFCVariesVariousWater & hydrogenRenewable storage~40–50% (emerging)

Benefits and Challenges: A Quick Recap

Benefits:

  • Zero local emissions (only water, heat, and some CO₂ for carbon-based fuels)
  • High fuel-to-electricity efficiency
  • Quiet operation
  • Scalable from milliwatts to megawatts
  • Compatible with renewable hydrogen production

Challenges:

  • Hydrogen infrastructure gaps (production, transport, storage)
  • Catalyst costs (especially platinum for PEMFC)
  • Durability and materials for high-temp systems
  • System complexity for reversible and hybrid applications

Final Thoughts

From zero-emission vehicles to backup power for hospitals and large industrial plants, fuel cells offer versatile, reliable, and scalable clean energy solutions. As green hydrogen production and fuel cell technologies advance, we can expect to see these systems powering more of our daily lives.

🌍 Fuel cells aren’t just the future — they’re here now, transforming transportation, industry, and our energy grids.

Second-life batteries

From EV to Home Storage: The Promise of Second-Life Batteries and the Role of SOH

When an electric vehicle (EV) battery no longer delivers the range you expect, is it truly the end of the road? Not necessarily! Welcome to the world of second-life batteries applications, where used EV batteries get a new lease on life powering our homes, businesses, and communities.

In this post, we’ll explore how State of Health (SOH) plays a crucial role in unlocking this sustainable energy solution.


Why Do EV Batteries Reach “End of Life”?

EV batteries typically reach their End of Life (EOL) for vehicle use when their capacity drops to around 70–80% of their original value. While this means they can’t reliably provide the range needed for daily driving, they still hold a significant amount of usable energy.

This is where the concept of second-life batteries comes in — putting these batteries to work in less demanding environments, like stationary battery energy storage systems.


What is a Second-Life Battery?

A second-life battery is a battery that has completed its first life in an electric vehicle and is repurposed for another application. Instead of sending it straight to recycling, these batteries can serve in home energy storage, backup power systems, or grid-scale applications.

Repurposing extends the overall lifespan of the battery materials, reduces waste, and makes clean energy storage more affordable.


The Role of SOH in Second-Life Battery Applications

State of Health (SOH) is the single most important metric for deciding whether a used battery is suitable for a second life. SOH indicates how much usable capacity and performance a battery still has compared to its original specification.

Without accurate SOH data, integrating second-life batteries into energy storage systems would be risky. A battery that looks fine externally might not hold a charge effectively — or worse, it could pose safety risks.

That’s why reputable second-life projects rely on robust SOH testing and screening processes. This ensures that only safe, reliable batteries find a second home.


Second-Life Batteries for Home Energy Storage

One of the most promising uses for second-life batteries is home energy storage. With rooftop solar becoming more common, many homeowners want to store excess solar energy for use at night or during power outages.

Second-life batteries can be an affordable alternative to brand-new battery systems. Here’s why they make sense:

  • Lower upfront cost: Second-life batteries are cheaper than new ones.
  • Sustainable use of resources: Reusing batteries delays recycling, saving the energy and emissions needed to produce new cells.
  • Adequate performance: Home energy storage is less demanding than powering a vehicle — fluctuations in capacity or power delivery are more manageable.

Challenges of Second-Life Batteries

Of course, second-life battery applications are not without challenges.

Variation in SOH: Each battery pack will have a unique SOH, so grading, sorting, and system design are crucial.
Warranty & standards: Consumers want to know their storage system is safe and reliable. Clear standards for SOH testing and certification are still evolving.
Safety: A degraded battery needs to be properly managed by a Battery Management System (BMS) to prevent thermal issues.


How SOH Testing Works

Evaluating SOH involves:

  1. Capacity tests: Measuring the charge the battery can hold.
  2. Internal resistance checks: Higher resistance indicates aging.
  3. Visual & diagnostic inspections: Identifying any physical damage or irregularities.

Advanced diagnostic tools and algorithms make it possible to test large numbers of used EV batteries quickly and reliably, paving the way for scalable second-life applications.


A Step Toward a Circular Battery Economy

By giving EV batteries a second life, we’re taking a big step toward a more circular economy for batteries. Instead of a single-use model, we maximize the value of the raw materials and reduce the demand for new mining.

This approach helps the clean energy transition become even more sustainable and cost-effective for everyone.


Final Thoughts

Second-life battery applications are an exciting example of how we can combine smart technology, sustainability, and practical economics. Next time you think your EV battery is ready for retirement, remember: with the help of accurate SOH measurement, it might just be ready to power your home instead.


FAQs: Second-Life Batteries & SOH

Q1: How long do second-life batteries last?

Second-life batteries can last 5–10 years or more in stationary applications, depending on their SOH and how they’re used.

Q2: Are second-life batteries safe for home use?

Yes — when properly tested for SOH, repurposed batteries are safe for less demanding energy storage applications. Always choose reputable suppliers with strong testing and BMS controls.

Q3: How is SOH measured for second-life batteries?

SOH is measured through capacity testing, resistance checks, and advanced diagnostics to ensure the battery still performs reliably.
